MAKE IN INDIA
Level 1: 5L / 10L / 15L
Level 1
5L / 10L / 15L
Our Level 1 Supercritical CO₂ Extraction Systems are designed for laboratory-scale for helping research, product development, and pilot extraction requirements. These compact systems offer precise control over pressure and temperature, making them ideal for testing formulations, optimizing extraction parameters, Enhancing product quality and small-batch production.
Level 1 systems are widely used for herbal/botanical extracts, medicinal compounds, essential oils, Aromatic extracts and specialty process applications where accuracy, stability, and purity are critical.
Technical Specifications
| Specification | Details |
|---|---|
| Single Extractor Volume | 5L / 10L / 15L |
| Number of Extractors | 1 or 2 (Optional) |
| Extraction Mode | Batch Type |
| Operating Pressure | Up to 400 Bar |
| Design Pressure | 600 Bar |
| Operating Temperature | 3°C – 70°C |
| CO₂ Circulation | Closed-loop System |
| Separator Configuration | Multi-stage Separation |
| CO₂ Pump Type | High-Pressure Triple Plunger Pump |
| Automation Level | Semi-automatic / Automatic |
| Construction of Material | SS 316 / SS 316L |
| Safety Features | Pressure relief valves, sensors, alarms |
System Features
Advanced pressure regulation ensures stable and accurate extraction conditions for targeted compounds.
Optimized CO₂ flow delivery improves extraction efficiency and repeatability across batches.
High-quality sealing components minimize leakage and reduce maintenance requirements.
Digital monitoring of pressure, temperature, and flow for reliable process control.
Engineered for durability and long operational life under high-pressure conditions.
Benefits
Cost-effective for research and pilot production
Faster extraction process
100% food-grade and non-toxic process
Non-flammable and environmentally safe
Minimal damage to raw materials
Reusable CO₂ with closed-loop circulation
High product stability and purity
GMP-compliant system design
Long lasting keeping quulity of products
Extract will be free from heavy metals
Frequently Asked Questions
Supercritical CO₂ extraction uses carbon dioxide above its critical temperature and pressure to selectively extract oils without harmful solvents.
Level 1 systems are ideal for herbal extracts, medicinal research, essential oils, fragrances, and R&D applications.
CO₂ gas is classified as GRAS (Generally Recognized As Safe)
